40 / 80 / 110
LPM flow rates
IKDAM AR SERIES · MADE IN ALGERIA
For high-demand stations
The AR5000 is IKDAM's flagship multi-product fuel dispenser for high-traffic forecourts — up to eight nozzles and multiple flow-rate options without compromising accuracy or throughput.
- AR18123
- Fuel Dispensers
1 to 8
Nozzles
LCD
Blue backlight display
±0.2%
Meter accuracy
Product overview
Built for high-demand stations, the AR5000 serves several vehicles and fuel grades at once. Multiple installation configurations, an LCD display with blue backlight, and shared IKDAM AR-series pump and volumetric meter technology deliver reliable, accurate dispensing.
Key features
Multi-product capacity
Up to eight nozzles for several vehicles and fuel grades simultaneously.
Selectable flow rates
Available at 40 LPM, 80 LPM and 110 LPM to match site throughput needs.
Clear LCD display
LCD with blue backlight for high visibility on the forecourt.
Flexible installation
Multiple configurations available to fit different station layouts.
Precision metering
Volumetric meter accuracy ±0.2% with repeatability ≤0.1% across the AR series.
Made in Algeria
Designed and manufactured by IKDAM for Algerian and regional forecourts.
TECHNICAL DATA
Technical specifications
AR5000 features and shared AR-series pump & meter data.
| Specification | Value |
|---|---|
| Model | AR5000 |
| Available flow rates | 40 LPM, 80 LPM, 110 LPM |
| Number of nozzles | 1 to 8 |
| Display | LCD with blue backlight |
| Installation types | Multiple configurations available |
| Meter flow range | 5 to 120 L/min |
| Meter accuracy | ±0.2% |
| Meter repeatability | ≤0.1% |
| Motor power | 0.75 to 1.5 kW |
| Pump flow | 45 to 120 L/min |
| Noise level | ≤71 dB |
Options
01
10-inch multimedia screen
Optional multimedia display for branding and customer information.
02
Electronic payment
Integration with electronic payment systems.
03
Vapor recovery
Optional vapor recovery system for compliant forecourt operation.
04
Custom paint
Custom colours to match your station identity.
Request a quotation
Contact IKDAM for pricing, configuration options and technical advice on the AR5000 fuel dispenser.
